Grape seed oil processing machine

Advantages: Low temperature, low pressure, high efficiency

Application: Grape seed oil, plant and animal oils, protein, pigments, herbal medicine



Product description

Henan Subcritical company is to provide solutions in the field of bio-processing of plants, animals and microorganisms, and to realize it by turnkey projects.

Currently, we can provide oil pretreatment machine, oil press, subcritical low-temperature extraction equipment, oil refining machine, molecular distillation machine, water extraction and alcohol extraction machine.

subcritical extraction machine

Definition of subcritical extraction technology: solvent in the temperature interval higher than its boiling point but lower than the critical point, under a certain pressure to liquefy the state exists, we define as the solvent's subcritical state. In this state using its similar soluble physical properties, used as a biological component extraction solvent for subcritical extraction solvent, the extraction process is called subcritical extraction process.

The solvents suitable for extraction and desolvation at room temperature and lower temperatures are defined as low-temperature subcritical solvents, and at present there are five types of low-temperature subcritical solvents suitable for industrial production, namely, propane, butane, DME, R134a, and liquid ammonia.

Subcritical extraction technology is an innovative and universal processing technology platform. Summarized in one sentence, subcritical extraction process is a low-temperature, low-pressure, high-efficiency physical method.

Grape seed oil processing machine

The fatty acid composition of grape seed oil is reasonable, and it is an excellent functional edible oil. The extraction methods of grape seed oil include pressing, organic solvent extraction, supercritical extraction and sub-critical low temperature extraction. The oil yield of the pressing method is low, the impurity content is high, and the high temperature is formed in the extrusion process, which destroys the unsaturated fatty acids in the oil. In the process of organic solvent extraction, the unsaturated fatty acids in the oil are destroyed and the nutritional value of the oil is greatly reduced. Supercritical CO2 extraction technology is used to produce grapeseed oil. Although there is no solvent residue, the process has high operating pressure (25 ~ 30 MPa), small equipment scale, large investment, and high production cost, resulting in the cost of grapeseed oil cannot be recognized by the market.

Our company adopts sub-critical low-temperature extraction technology to extract grape seed oil, which makes up for the shortcomings of the above production process. Subcritical (the main solvent is butane, propane) extraction technology, is a new extraction technology in food processing industry, with low boiling point of solvent, gas under normal temperature and pressure, easy to volatilizing characteristics. Subcritical extraction of grape seed oil is to extract and separate grape seed oil from raw materials by using its characteristics.

Advantages of subcritical extraction technology

Compared with hexane and other conventional solvent extraction process, low-temperature subcritical extraction process has the following outstanding advantages:

1. the material in the heat-sensitive components of the damage is small, suitable for the extraction of plant components, herbal ingredients extraction;

2. the loss of volatile essential oils is small, the components of the whole, the taste is pure and suitable for the extraction of essential oils of plants;

3. energy saving, energy-saving solvent evaporation is less energy-consuming, the desolvation process does not have to make the material warming up;

4. with a certain degree of selective extraction advantages.

Compared with supercritical carbon dioxide extraction process, low-temperature subcritical extraction process has the advantages of high efficiency, low pressure, as well as the advantages of small investment, low production costs, large production scale.






1. Outside package: Standard marine export plywood case.

2. inner package: Stretchy film and plastic film for humidity.

3. We can package according to your requests.

4. Engineer available to service machinery overseas.

Delivery Detail: based on the contract.






Q1: Are you a trading company or a manufactory?

A1: We are a manufactory, we supply the factory price with good quality, welcome to visit !

Q2: What’s your guarantee or the warranty of the quality if we buy your machines?

A2: We offer you high quality machines with 1 year guarantee and supply life-long technical support.

Q3: When can I get my machine after I paid?

A3: The delivet time is based on the exact machine you confirmed.

Q4: How can I install my machine when it arrives?

A4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.

Q5: How about the spare parts?

A5: After we deal down all the things , we will offer you a spare parts list for your reference.



Henan Subcritical Machinery Equipment Co., Ltd. is located in Anyang High-tech Zone equipment park, engaged in natural products low-temperature extraction engineering design, complete equipment installation, commissioning and personnel training.

The company has strong technical force, two State Council special allowance experts, more than 30 engineering and technical personnel, with nearly 30 years of subcritical low-temperature extraction engineering design and installation experience. Holds the "subcritical" trademark in China.

The company has oil engineering department, plant protein engineering department, plant pigment engineering department, engineering installation department, equipment manufacturing workshop, workshop and electrical automation assembly workshop.

Our company has a complete set of extraction equipment production, installation team of more than 100 people. It has undertaken more than 100 subcritical low-temperature extraction projects at home and abroad, mainly undertakes complete sets of production lines for low-temperature extraction of functional oils, such as extraction of natural pigments, essential oils, spice oils, precious oils, as well as the manufacturing of pressure vessels, molecular distillation, deplasticizer equipment, alcohol extraction equipment.

Company motto: Be honest, do earnestly!



Why choose Henan Subcritical Machinery?

We are an integrated service provider of complete sets of oil extraction equipment, providing turnkey solutions for natural product extraction.

Technical Advantage

More than 30 years of manufacturing experience, continuous technological innovation, favorable price.

Experience advantage

Over the years, we have served thousands of companies and sold our products all over the country.

Manufacturing Advantage

Various types of equipment, strict quality control, to meet customer needs.

Service Advantage

Professional maintenance services, provide perfect after-sales solutions.
